CONREVSMA007-R58 Arkusz danych(PDF) 1 Page - List of Unclassifed Manufacturers

Numer części CONREVSMA007-R58
Szczegółowy opis  RP-SMA MALE CABLE END CRIMP FOR RG58 CABLE
PDF  1 Pages
Scroll/Zoom Zoom In 100%  Zoom Out
Producent  ETC2 [List of Unclassifed Manufacturers]
Strona internetowa
Logo ETC2 - List of Unclassifed Manufacturers

CONREVSMA007-R58 Arkusz danych(HTML) 1 Page - List of Unclassifed Manufacturers

  CONREVSMA007-R58 Datasheet HTML 1Page - List of Unclassifed Manufacturers
Zoom Inzoom in Zoom Outzoom out
 1 / 1 page
background image
A
B
C
D
4
3
2
1
D
C
B
A
1
2
4
3
RP-SMA MALE CABLE END
CRIMP FOR RG58 CABLE
0.276
(7.00)
0.079
(2.00)
RECOMMENDED CABLE STRIPPING DIMENSIONS
0.118
(3.00)
RG-58 Cable
1.
Solder the socket to the center conductor.
2.
Insert the socket, center conductor, and insulator into the body
until the top of the socket is even with the white insulation in the body.
3.
Wrap the braid around the tail of the body and crimp the ring with a
hex crimp tool.
CONREVSMA007-R58 ASSEMBLY INSTRUCTIONS
Description
Material
Finish
Body
Socket
Insulation
Nickel
Teflon
Gold
Teflon
Brass
BE CU
Washer
PH Bronze
Gold
Gasket
Rubber
SI Rubber
Crimp Ring
Nickel
Brass
CONNECTOR CITY
159 ORT LANE
MERLIN, OR 97532
PH (541)-471-6256
FAX (541)-471-6251
Date:
Sheet 1 of 1
Revision:
Title
Part No.
Dimensions:
CONREVSMA007-R58
1.0
INCHES (mm)
6/1/2006
0.500
(12.70)
Ø0.256
(6.50)
0.240
(6.10)
Ø0.039
(1.00)
Ø0.049
(1.25)
Ø0.024
(0.60)
PIN CHUCK
0.2x2x2 GROOVE
0.276
(7.00)
0.656
(16.65)
Ø0.126
(3.20)
Ø0.177
(4.50)
1/4-36UNF-2B
THREADS
H0.311
(7.90)
SIDE VIEW
SOCKET
CRIMP RING
