SK8552

LINEAR INTEGRATED CIRCUIT

UNISONICTECHNOLOGIESCO.,LTD

3 of 5

www.unisonic.com.tw

QW-R118-006,F



PARAMETER

SYMBOL

RATINGS

UNIT

Supply Voltage

3~20

V

Supply Current

10

mA

Output Current

10

mA

Power Dissipation

SIP-3

400

mW

SOT-25

200

mW

Junction Temperature

+125

C

Operating Temperature

-20~ +125

C

Storage Temperature

-55~+150

C

Note 1. Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.



PARAMETER

SYMBOL

CONDITIONS

MIN TYP MAX UNIT

Output voltage SH

2.8

3

V

Output voltage NH

2.8

3

V

Output voltage SL

0.7

V

Output voltage NL

0.7

V

Output current 1

10

mA

Output current 2

10

mA

Supply current

5

mA

Output switching time

5

μS

1

μS

MAGNETIC CHARACTERISTICS

(over operating supply voltage range)

Operating magnetic flux density

BHLS

20

G

Operating magnetic flux density

BHLN

-20

G

Operating magnetic flux density

BLHS

100

G

Operating magnetic flux density

BLHN

-100

G
