TECHNICAL DATA SHEET

Configuration

Connector

MCX Jack

Connector Interface Type

.068 inch End Launch

Attachment Method (Shield/Contact)

Solder

Body Style

Straight

Electrical Specifications

Impedance

75 Ohms

Mechanical Specifications

Size

Length

0.361 in [9.17 mm]

Width/Dia.

0.25 in [6.35 mm]

Height

0.25 in [6.35 mm]

.

Weight

0.004 lbs [1.81 g]

Connector

Type

MCX Jack

Contact Material and Plating

Gold

Body Material and Plating

Brass, Gold

Dielectric Type

PTFE

Not RoHS Compliant

Plotted and Other Data

Notes:

• Values at +25 °C, sea level

75 Ohm MCX Jack Connector Solder Attachment 0.068 inch End Launch PCB from Pasternack Enterprises has same day

shipment for domestic and International orders. Our RF, microwave and millimeter wave products maintain a 99% availability

and are part of the broadest selection in the industry.

Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,

inventory and certifications: 75 Ohm MCX Jack Connector Solder Attachment 0.068 inch End Launch PCB PE44305

URL: http://www.pasternack.com/mcx-jack-standard-0.068-end-launch-connector-pe44305-p.aspx

PE44305

PE44305 REV 1.1

75 Ohm MCX Jack Connector Solder

Attachment 0.068 inch End Launch PCB
