MSC0291.PDF 04-20-00

8700 E. Thomas Road

Scottsdale, AZ 85252

Phone: (480) 941-6300

Fax:

(480) 947-1503

MLL746A,-1 thru MLL759A,-1

and

MLL4370A,-1 thru MLL4372A,-1

±1% and ±2% Versions

“C” and “D” Available

Features

•

Leadless Package For Surface Mount Technology

•

Ideal For High Density Mounting

•

Voltage Range 2.4 To 12 Volts

•

Hermetically Sealed, Double Slug Glass Construction

•

Metallurgically Bonded Construction Available as Dash One.

•

Available in JAN, JTX, JTXV-1 To Mil-PRF-19500/127 (UR-1 Suffix)

MILLIMETERS

INCHES

DIM

MIN

MAX

MIN

MAX

A

3.30

3.70

.130

.146

B

1.60

1.70

.063

.067

U

0.41

0.55

.016

.022

LEADLESS GLASS

ZENER DIODE

SURFACE MOUNT

Mechanical

Characteristics

Case: Hermetically sealed glass with solder

contact tabs at each end.

Finish: All external surfaces are corrosion

resistant, readily solderable.

Polarity: Banded end is cathode.

Thermal Resistance: 100

°C/Watt Maximum

junction to end caps for "-1" construction and

150

°C/W maximum junction to end caps for

commercial.

Mounting Position: Any

Weight: 0.04 gm

Maximum Ratings

500 mW DC Power Dissipation (See Power Derating Curve In Figure 1)

-55

°C to +175°C Operating and Storage Junction Temperature

Application

This surface mountable zener diode series is similar to the 1N746 thru

1N759 in the DO-35 equivalent package except that it meets the new

JEDEC surface mount outline DO-213AA. It is an ideal selection for

applications of high density and low parasitic requirements. Due to its

glass hermetic qualities, it may also be considered for high reliability

applications.

Electrical Characteristics @ 25

°C

MICROSEMI

PART

NUMBER

NOMINAL

ZENER

VOLTAGE

(NOTE 1)

ZENER

TEST

CURRENT

MAXIMUM

ZENER

IMPEDANC

E

(NOTE 2)

MAXIMUM

REVERSE CURRENT

@25

°°°°C

@ +150

°°°°C

MAXIMUM

ZENER

CURRENT

(NOTE 4)

TYPICAL

TEMP

COEFF. OF

ZENER

VOLTAGE

α

αα

α

VZ

**

VOLTS

mA

OHMS

µµµµA

µµµµA

mA

%/

°°°°C

MLL4370A

2.4

20

30

100

200

150

- .085

MLL4371A

2.7

20

30

75

150

135

- .080

MLL4372A

3.0

20

29

50

100

120

- .075

MLL746A

3.3

20

28

10

30

110

- .066

MLL747A

3.6

20

24

10

30

100

- .058

MLL748A

3.9

20

23

10

30

95

- .046

MLL749A

4.3

20

22

2

30

85

- .033

MLL750A

4.7

20

19

2

30

75

- .015

MLL751A

5.1

20

17

1

20

70

±±±±.010

MLL752A

5.6

20

11

1

20

65

+.030

MLL753A

6.2

20

7

.1

20

60

+.049

MLL754A

6.8

20

5

.1

20

55

+.053

MLL755A

7.5

20

6

.1

20

50

+.057

MLL756A

8.2

20

8

.1

20

45

+.060

MLL757A

9.1

20

10

.1

20

40

+.061

MLL758A

10.0

20

17

.1

20

35

+.062

MLL759A

12.0

20

30

.1

20

30

+.062

Note 1 Voltage measurements to be performed 20 seconds after application of dc

test current.

increase in junction temperature as the unit approaches thermal equilibrium at the

power dissipation at 500 mW.

** Ordering Information:

1) Commercial: MLL746A thru MLL759A or MLL746A-1 thru MLL759A-1

MLL4370A thru MLL4372A or MLL4370A-1 thru MLL4372A-1

2) Military: JAN, JANTX, or JANTXV 1Nxxxx UR-1

3) Tight tolerance "C" suffix = ±2%, "D" suffix = ±1%

DO-213AA

Package Dimensions In Inches
