6 / 21 page

ADP5301

Data Sheet

Rev. A | Page 6 of 21

ABSOLUTE MAXIMUM RATINGS

Table 2.

Parameter

Rating

PVIN to PGND

−0.3 V to +7 V

SW to PGND

−0.3 V to PVIN + 0.3 V

FB to AGND

−0.3 V to +7 V

VID to AGND

−0.3 V to +7 V

EN to AGND

−0.3 V to +7 V

VOUTOK to AGND

−0.3 V to +7 V

SYNC/MODE to AGND

−0.3 V to +7 V

PGND to AGND

−0.3 V to +0.3 V

Storage Temperate Range

−65°C to +150°C

Operational Junction Temperature Range

−40°C to +125°C

Stresses at or above those listed under Absolute Maximum

Ratings may cause permanent damage to the product. This is a

stress rating only; functional operation of the product at these

or any other conditions above those indicated in the operational

section of this specification is not implied. Operation beyond

the maximum operating conditions for extended periods may

affect product reliability.

THERMAL RESISTANCE

θJA is specified for the worst case conditions, that is, a device

soldered in a circuit board for surface-mount packages.

Table 3. Thermal Resistance

Package Type

θJA

Unit

9-Ball WLCSP

132

°C/W

ESD CAUTION
