background image
INCHANGE Semiconductor
isc Product Specification
isc website：www.iscsemi.cn
isc & iscsemi is registered trademark
2
isc N-Channel Mosfet Transistor
IRF044
·ELECTRICAL CHARACTERISTICS (TC=25℃)
SYMBOL
PARAMETER
CONDITIONS
MIN
TYPE
MAX
UNIT
V(BR)DSS
Drain-Source Breakdown Voltage
VGS=0; ID=1mA
60
V
VGS(TH)
Gate Threshold Voltage
VDS= VGS; ID=250µA
2.0
4.0
V
RDS(ON)
Drain-Source On-stage Resistance
VGS=10V; ID=27A
0.028
Ω
IGSS
Gate Source Leakage Current
VGS=±20V;VDS=0
±100
nA
IDSS
Zero Gate Voltage Drain Current
VDS=48V; VGS=0
25
uA
VSD
Diode Forward Voltage
IS=44A; VGS=0
2.5
V
Ciss
Input Capacitance
VDS=25V;
VGS=0V;
fT=1MHz
2400
pF
Crss
Reverse Transfer Capacitance
230
Coss
Output Capacitance
1100
tr
Rise Time
ID=44A;
VDD=30V;
RL=9.1Ω
130
ns
td(on)
Turn-on Delay Time
23
tf
Fall Time
79
td(off)
Turn-off Delay Time
81
