9 / 26 page

www.ti.com

0.05

0.1

0.15

0.2

Typical for All Channels

VDD = 2.7 V,

VREF = 2.5 V

VDD = 5.5 V,

VREF = 4.096 V

ISINK − Sink Current − mA

DAC Loaded with 000h

5.20

5.30

5.40

5.50

Typical for All Channels

VDD = VREF = 5.5 V

ISOURCE − Source Current − mA

DAC Loaded with FFFh

2.4

2.5

2.6

2.7

Typical for All Channels

VDD = VREF = 2.7 V

ISOURCE − Source Current − mA

DAC Loaded with FFFh

100

150

200

250

300

350

400

512

1024 1536 2048 2560 3072 3584 4096

Digital Input Code

VDD = 5.5 V,

VREF = 4.096 V

VDD = 2.7 V,

VREF = 2.5 V

All Channels Powered, No Load

DAC7553

SLAS477 – SEPTEMBER 2005

TYPICAL CHARACTERISTICS (continued)

SINK CURRENT AT NEGATIVE RAIL

SOURCE CURRENT AT POSITIVE RAIL

Figure 10.

Figure 11.

SOURCE CURRENT AT POSITIVE RAIL

SUPPLY CURRENT

DIGITAL INPUT CODE

Figure 12.

Figure 13.
