background image
PL620-88/-89
Low Phase Noise XO (9.5-65MHz Output)
Micrel Inc. • 2180 Fortune Drive • S an Jose, CA 95131 • USA • tel +1(408) 944-0800 • fax +1(408) 474-1000 • www.micrel.com
Rev 4/28/09 Page 3
2. Crystal Specifications
PARAMETERS
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
Crystal Resonator Frequency
FXIN
Fundamental
19
65
MHz
Crystal Loading Rating
CL (xtal)
8.5
pF
Interelectrode Capacitance
C0
5
pF
Recommended ESR
RE
AT cut
30
Ω
3. General Electrical Specifications
PARAMETERS
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
Supply Current (Loaded Outputs)
IDD
LVPECL/LVDS, 15pF Load
100/80
mA
Operating Voltage
VDD
2.25
3.63
V
Output Clock Duty Cycle
@ 1.25V (LVDS)
@ VDD – 1.3V (LVPECL)
45
50
55
%
Short Circuit Current
50
mA
4. Jitter Specifications
PARAMETERS
CONDITIONS
MIN
TYP
MAX
UNITS
Period jitter RMS at 27MHz
With capacitive decoupling
between VDD and GND. Over
10,000 cycles
2.3
ps
Period jitter peak-to-peak at 27MHz
18.5
20
Accumulated jitter RMS at 27MHz
With capacitive decoupling
between VDD and GND. Over
1,000,000 cycles.
2.3
ps
Accumulated jitter pk-to-pk at 27MHz
24
25
Random Jitter
“RJ” measured on Wavecrest
SIA 3000
2.3
ps
Measured on Wavecrest SIA 3000
5. Phase Noise Specifications
PARAMETERS
FREQUENCY
@10Hz
@100Hz
@1kHz
@10kHz
@100kHz
UNITS
Phase Noise
relative to carrier
27MHz
-75
-100
-125
-140
-145
dBc/Hz
Note: Phase Noise measured on Agilent E5500
