PL602-35/-37/-38/-39

750kHz

– 800MHz Low Phase Noise Multiplier XO

Universal Low Phase Noise IC’s

Micrel Inc. • 2180 Fortune Drive • San Jose, CA 95131 • USA • tel +1(408) 944 -0800 • fax +1(408) 474-1000 • www.micrel.com Rev 03/07/2012 Page 5

4. Jitter Specifications

PARAMETERS

CONDITIONS

FREQUENCY

MIN.

TYP.

MAX.

UNITS

Period Jitter,

RMS

With capacitive decoupling

between VDD and GND.

Over 10,000 cycles.

155.52MHz

4.3

622.08MHz

5.0

Period Jitter,

Peak-to-Peak

With capacitive decoupling

between VDD and GND.

Over 10,000 cycles.

155.52MHz

622.08MHz

Integrated Jitter,

RMS

Integrated 12 kHz to 20 MHz

155.52MHz

2.4

622.08MHz

2.5

5. Phase Noise Specifications

PARAMETERS

FREQUENCY

@10Hz

@100Hz

@1kHz

@10kHz

@100kHz

UNITS

Phase Noise,

relative to carrier

(typical)

155.52MHz

-63

-93

-117

-126

-123

dBc/Hz

622.08MHz

-52

-83

-105

-113

-110

6. LVCMOS Electrical Characteristics

PARAMETERS

SYMBOL

CONDITIONS

MIN.

TYP.

MAX.

UNITS

Output drive current

IOH

VOH= VDD-0.4V, VDD=3.3V

IOL

VOL = 0.4V, VDD = 3.3V

Output Clock Rise/Fall Time

0.3V ~ 3.0V with 15 pF load

2.4
