(Preliminary)

PL123E-05

Low Skew Zero Delay Buffer

Absolute Maximum Conditions

Supply Voltage to Ground Potential ...... –0.5V to 4.6V

Storage Temperature ......................... –65°C to 150°C

Junction Temperature ....................................... 150°C

Static Discharge Voltage

(per MIL-STD-883, Method 3015)………………> 2000V

Operating Condition

Description

Parameter

Min

Max

Unit

Supply Voltage

2.25

3.63

V

Load Capacitance, <100 MHz, 3.3V

–

30

pF

Load Capacitance, <100 MHz, 2.5V with High Drive

–

30

pF

Load Capacitance, <133.3 MHz, 3.3V

–

22

pF

Load Capacitance, <133.3 MHz, 2.5V with High Drive

–

22

pF

Load Capacitance, <133.3 MHz, 2.5V with Standard Drive

–

15

pF

Load Capacitance, >133.3 MHz, 3.3V

–

15

pF

Load Capacitance, >133.3 MHz, 2.5V with High Drive

–

15

pF

–

5

pF

Closed-loop bandwidth (typical), 3.3V

BW

1

MHz

Closed-loop bandwidth (typical), 2.5V

0.5

MHz

Output Impedance (typical), 3.3V Hi gh Drive

23

Ω

Output Impedance (typical), 3.3V Standard Drive

33

Ω

Output Impedance (typical), 2.5V High Drive

26

Ω

Output Impedance (typical), 2.5V Standard Drive

39

Ω

voltage (power ramps must be monotonic)

0.01

250

ms

Notes:

4. Applies to Test Circuit #1.

5. Applies to both REF Clock and internal feedback path on CLKOUT.

6. Theta Ja, EIA JEDEC 51 test board conditions, 2S2P; Theta Jc Mil-Spec 883E Method 1012.1.
