PL138-48

DS20005543B-page 4

 2016 Microchip Technology Inc.

AC ELECTRICAL CHARACTERISTICS

f ≤ 800 MHz unless otherwise noted.

Parameters

Symbol

Min.

Typ.

Max.

Units

Conditions

Output Frequency

—

—

800

MHz

At all temperatures

600

680

750

ps

At –40°C

650

725

790

At +25°C

690

790

890

At +85°C

—

25

37

ps

At all temperatures

Part-to-Part Skew, (Note 3,

Note 4)

—

85

225

ps

At all temperatures

Buffer Additive Phase Jitter,

RMS

—

—

0.10

ps

At all temperatures; refer to

Noise Characteristics

section

Peak-to-Peak Input Voltage

(Differential Configuration)

150

800

1200

mV

At all temperatures

Peak-to-Peak Output Voltage

470

800

950

mV

At –40°C

600

800

930

At +25°C

600

800

930

At +85°C

Output Rise/Fall Time

200

—

550

ps

At all temperatures; 20% to

80% at full output swing.

Note 1: Measured from the differential input crossing point to the differential output crossing point.

2: Defined as skew between outputs at the same supply voltage and with equal load conditions. Measured at

the output differential cross points.

3: Defined as skew between outputs on different devices operating at the same supply voltages and with

equal load conditions. Using the same type of inputs on each device, the outputs are measured at the dif-

ferential cross points.

4: This parameter is defined in accordance with JEDEC Standard 65.
