7.3 x 6.8 x 3.0 mm

ASPI-7318

ELECTRICAL SPECIFICATIONS:

RoHS

Compliant

30332 Esperanza, Rancho Santa Margarita, California92688

Revised: 10.11.12

Visit www.abracon.com for Terms & Conditions of Sale

HIGH CURRENT SHIELDED POWER INDUCTOR

FEATURES:

APPLICATIONS:

Pb

ABRACON IS

ISO9001:2008

CERTIFIED

Abracon P/N:

ASPI-7318-xxx

Operating Temperature :

-55ºC to +125ºC

Storage Temperature

Part Number

L

Tolerance

ASPI-7318-

Inductance Code

(µH)

(M, N)

mΩ

(A)

(A)

ASPI-7318-R10

0.10

N

1.7

50

30

ASPI-7318-R15

0.15

N

2.5

45

26

ASPI-7318-R20

0.20

N

3.0

41

24

ASPI-7318-R22

0.22

N

3.1

34

22

ASPI-7318-R33

0.33

M

3.9

28

20

ASPI-7318-R47

0.47

M

4.2

24

17.5

ASPI-7318-R56

0.56

M

5.3

23

15.5

ASPI-7318-R68

0.68

M

5.5

22

15.5

ASPI-7318-R82

0.82

M

8.0

19

13

ASPI-7318-1R0

1.0

M

10.0

17

11

ASPI-7318-1R5

1.5

M

15

15

9

ASPI-7318-2R2

2.2

M

20

12

8

ASPI-7318-2R5

2.5

M

22

11

8

ASPI-7318-3R3

3.3

M

30

10

6

ASPI-7318-4R7

4.7

M

40

8

5

ASPI-7318-5R6

5.6

M

54

7.5

5

ASPI-7318-6R8

6.8

M

60

7

4.5

ASPI-7318-8R2

8.2

M

68

6

4

ASPI-7318-100

10.0

M

105

5.5

3

ASPI-7318-220

22.0

M

230

3

2

Test Conditions

1. Inductance tested at 200kHz, 0.25V, 0A; Tolerance M=±20%; N=±30%

2. All test data is in reference to 25°C ambient.

3. Isat will cause the inductance value to drop approximately 20%

4. Irms will cause an approximate ΔT of 40°C

5. The part temperature (ambient + temp. rise) should not exceed 125°C under worst case operating

conditions. Circuit design, component placement, PWB trace size and thickness, airflow and other

cooling provisions all affect the part temperature. Part temperature should be verified in the end

application.

6. Please contact Abracon for the availability of other inductance values.

Less than +25˚C, Humidity<75% RH.

MSL Level:1
