AD8221

Rev. C | Page 8 of 24

ABSOLUTE MAXIMUM RATINGS

Table 3.

Parameter

Rating

Supply Voltage

±18 V

Internal Power Dissipation

200 mW

Output Short-Circuit Current

Indefinite

Input Voltage (Common-Mode)

±V

Differential Input Voltage

±V

Storage Temperature Range

−65°C to +150°C

Operating Temperature Range1

−40°C to +125°C

1 Temperature range for specified performance is –40°C to +85°C. See Typical

Performance Characteristics for expected operation from 85°C to 125°C.

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

THERMAL CHARACTERISTICS

Specification for a device in free air.

Table 4.

Package

Unit

8-Lead SOIC, 4-Layer JEDEC Board

121

°C/W

8-Lead MSOP, 4-Layer JEDEC Board

135

°C/W

ESD CAUTION
