Recommended operating conditions
LED6001
8/26
DocID025575 Rev 3
5
Recommended operating conditions
Table 5. Recommended operating conditions
Symbol
Parameter
Conditions
Min.
Max. Unit
DC characteristics
VVIN
Supply input voltage range
5.5
36
V
VVDR
VDR pin Input voltage range
VDR and VIN shorted together
4.7
5.5
VVFBx
Feedback input common mode
voltage range
4.4
60
VFB
Feedback input differential mode
voltage range
VFBP to VFBN
30
300
mV
AC characteristics
fsw
Switching frequency
100
1000
kHz
fPWMI
Dimming frequency
0.1
20
tPWMI,en
Minimum PWMI pulse duration for
device enable (turn on)
PWMI input, fSW = 800 kHz
100
µs
tPWMI,dim
Minimum dimming on-time
PWMI input, fSW = 1 MHz
6
µs



Html Pages
