AD7989-1/AD7989-5

Rev. B | Page 7 of 24

ABSOLUTE MAXIMUM RATINGS

Table 6.

Parameter

Rating

Analog Inputs

IN+, IN− to GND1

−0.3 V to VREF + 0.3 V or ±130 mA

Supply Voltage

REF, VIO to GND

−0.3 V to +6.0 V

VDD to GND

−0.3 V to +3.0 V

VDD to VIO

+3 V to −6 V

Digital Inputs to GND

−0.3 V to VIO + 0.3 V

Digital Output to GND

−0.3 V to VIO + 0.3 V

Storage Temperature Range

−65°C to +150°C

Junction Temperature

150°C

θJA Thermal Impedance

10-Lead MSOP

200°C/W

10-Lead LFCSP

48.7°C/W

θJC Thermal Impedance

10-Lead MSOP

44°C/W

10-Lead LFCSP

2.96°C/W

Reflow Soldering

JEDEC Standard (J-STD-020)

1 See the Analog Inputs section for an explanation of IN+ and IN−.

Stresses at or above those listed under Absolute Maximum

Ratings may cause permanent damage to the product. This is a

stress rating only; functional operation of the product at these

or any other conditions above those indicated in the operational

section of this specification is not implied. Operation beyond

the maximum operating conditions for extended periods may

affect product reliability.
