Transformers

Designer’s Kit K1-TCN+

RF/IF & MICROWAVE COMPONENTS

P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661 For quick access to product information see MINI-CIRCUITS CATALOG & WEB SITE

ISO 9001 ISO 14001 AS 9100 CERTIFIED

600 to 2600 MHz

TCN+ Features

•

Balanced transmission line

•

Very wide bandwidth

•

Rugged LTCC construction

•

Small size, 0.12” (L) x .06” (W) x .037” (H)

•

Low cost

o S

C O M P L I A N T

All models are

RoHS compliant

MINI-CIRCUITS DESIGNER’S KITS

THE SOLUTION !

Model

Config-

Ω

Frequency

Insertion

Phase

Amplitude

uration

Ratio

( MHz)

Loss

Unbal.

(dB)

Typ.

TCN1-10+

G

1

680-1050

0.9

4

0.7

TCN1-23+

G

1

1300-2300

0.7

5

0.7

TCN2-14+

G

2

700-1400

0.8

8

0.7

TCN2-26+

G

2

1600-2600

0.75

4

0.6

TCN3-11+

G

3

600-1100

0.7

6

1

TCN4-13+

G

4

650-1250

1.0

8

0.7

TCN4-22+

J

4

1200-2200

1.0

10

0.6

Kit K1-TCN+ Electrical specifications of each model

only

5995

$

ea. kit (7 models, 5 of each, 35 total)

* Insertion loss is referenced to mid-band loss.

Configurations

G

J

®

REV. OR

M108655

K1-TCN+
