CS7666

DS302PP1

Master Reset Register (00h)

Setting bit MR0 to logic high will initiate a CS7666 master reset equivalent to executing an ex-

ternal reset using the RESET pin. All registers will be placed in their default state, and the down-

load of any external EPROM present on the secondary I2C bus will be initiated. The bit is self-

cleared.

Status Register (01h)

EVNFLD

Logic high indicates even field of interline-transfer CCD. Logic low indicates odd field of inter-

line-transfer CCD. This bit provides a course means of synchronizing to the field rate.

NODEV

Logic high indicates that the addressed slave device on the secondary I2C bus did not respond.

I2CBUSY

Logic high indicates that the CS7666 secondary I2C master is busy accessing the addressed

slave device.

INITACT

Logic high indicates the CS7666 master is busy initializing registers from the external I2C

EPROM on the secondary I2C bus (if present).

HIZENB

Pin 63 status.

INTERP

Pin 54 status.

P4BYTE

Pin 1 status.

PIN I/O Control (02h)

PLLOUT

Logic high enables the PLL clock output to the CS7615 (pin 51). This pin was a NC on the

CS7665.

FIELDOUT

Logic high changes FIELD (pin 62) from an input to an output pin. Default is input.

UV_ENB

Logic high replaces FIELD with a U/V clock.

Digital Gain Register (03h)

DG[4:0]

Controls the digital gain applied to the Y (Luminance) signal after the RGB to YCrCb converter

block. The range of gains are from 0 to 31/8 in increments of 1/8. A gain of 0, indicates no bright-

ness.

76543210

res

Reserved

76543210

res

P4BYTE

INTERP

HIZENB

INITACT

I2CBUSY

NODEV

EVNFLD

Reserved

RRRRRRR

76543210

res

UV_ENB

FIELDOUT

PLLOUT

Reserved

R/W

76543210

res

DG4

DG3

DG2

DG1

DG0

Reserved

R/W
