www.markimicrowave.com

MMD-3580L

Copyright © 2019 Marki Microwave, Inc.

3. Specifications

3.1 Absolute Maximum Ratings

The Absolute Maximum Ratings indicate limits beyond which damage may occur to the

device. If these limits are exceeded, the device may be inoperable or have a reduced

lifetime.

Parameter

Maximum Rating

Units

Port 1 DC Current

NA

mA

Port 2 DC Current

NA

mA

Power Handling, at any Port

+23

dBm

Operating Temperature

-55 to +100

°C

Storage Temperature

-65 to +125

ºC

3.2 Package Information

Parameter

Details

Rating

ESD

Human Body Model (HBM), per MIL-STD-750, Method 1020

1A

Weight

U Package

10 g

3.3 Recommended Operating Conditions

The Recommended Operating Conditions indicate the limits, inside which the device should

be operated, to guarantee the performance given in Electrical Specifications Operating

outside these limits may not necessarily cause damage to the device, but the

performance may degrade outside the limits of the electrical specifications. For limits,

above which damage may occur, see Absolute Maximum Ratings.

Min

Nominal

Max

Units

-55

+25

+100

°C

Input Power

+7

+11

dBm

3.4 Sequencing Requirements

There is no requirement to apply power to the ports in a specific order. However, it is

recommended to provide a 50Ω termination to each port before applying power. This is a

passive diode doubler that requires no DC bias.
