OUTLINE DIMENSIONS

0.80

0.75

0.70

1.175

1.075

0.975

0.876

0.776

0.676

0.40

BSC

0.40

0.35

0.30

0.25

0.20

0.15

BOTTOM VIEW

TOP VIEW

SIDE VIEW

EXPOSED

PAD

3.10

3.00 SQ

2.90

0.050 MAX

0.035 NOM

0.152 REF

COPLANARITY

0.08

DETAIL A

(JEDEC 95)

P IN 1

IN D I C AT O R AR E A OP T IO N S

(SEE DETAIL A)

PIN 1

INDICATOR

AREA

SEATING

PLANE

FOR PROPER CONNECTION OF

THE EXPOSED PAD, REFER TO

THE PIN CONFIGURATION AND

FUNCTION DESCRIPTIONS

SECTION OF THIS DATA SHEET.

Figure 126. 20-Lead Lead Frame Chip Scale Package [LFCSP]

3 mm × 3 mm Body and 0.75 Package Height

(CP-20-19)

Dimensions shown in millimeters

ORDERING GUIDE

Model1

Temperature Range

Package Description

Package Option

ADRF6521ACPZ

−40°C to +85°C

20-Lead Lead Frame Chip Scale Package [LFCSP]

CP-20-19

ADRF6521ACPZ-R7

−40°C to +85°C

20-Lead Lead Frame Chip Scale Package [LFCSP], 7”Tape and Reel

CP-20-19

ADRF6521-EVALZ

Evaluation Board

Z = RoHS Compliant Parts.

registered trademarks are the property of their respective owners.

D24784-11/20(0)
