Data Sheet

ADP5014

Rev. A | Page 7 of 34

ABSOLUTE MAXIMUM RATINGS

Table 3.

Parameter

Rating

AVIN to Ground

−0.3 V to +6.5 V

PVIN1 to PGND1

−0.3 V to +6.5 V

PVIN2 to PGND2

−0.3 V to +6.5 V

PVIN3 to PGND3

−0.3 V to +6.5 V

PVIN4 to PGND4

−0.3 V to +6.5 V

SW1 to PGND1

−0.3 V to +6.5 V

SW2 to PGND2

−0.3 V to +6.5 V

SW3 to PGND3

−0.3 V to +6.5 V

SW4 to PGND4

−0.3 V to +6.5 V

PGND to Ground

−0.3 V to + 0.3 V

CFG1, CFG2 to Ground

−0.3 V to +6.5 V

EN1/ENALL, EN2/DL12, EN3/UV,

EN4/DL34 to Ground

−0.3 V to +6.5 V

GPIO to Ground

−0.3 V to +6.5 V

RT to Ground

−0.3 V to +6.5 V

VREF to Ground

−0.3 V to +6.5 V

FB1, FB2, FB3, FB4 to Ground 1

−0.3 V to +6.5 V

COMP1, COMP2, COMP3, COMP4

to Ground

−0.3 V to +6.5 V

VSET1, VSET2, VSET3, VSET4 to

Ground

−0.3 V to +6.5 V

Storage Temperate Range

−65°C to +150°C

Operational Junction Temperature

Range

−40°C to +125°C

The rating for the FB1, FB2, FB3, and FB4 pins applies to the adjustable

output voltage models of the ADP5014.

Stresses at or above those listed under Absolute Maximum

Ratings may cause permanent damage to the product. This is a

stress rating only; functional operation of the product at these

or any other conditions above those indicated in the operational

section of this specification is not implied. Operation beyond

the maximum operating conditions for extended periods may

affect product reliability.

THERMAL RESISTANCE

Thermal performance is directly linked to printed circuit board

(PCB) design and operating environment. Close attention to

PCB thermal design is required.

Table 4. Thermal Resistance

Package Type

θJA

θJC

Unit

CP-40-10

11.1

°C/W

ESD CAUTION
