Table 10. SO-8 package mechanical data
Dim.
mm
Notes
Min.
Typ.
Max.
A
1.35
1.75
A1
0.1
0.25
b
0.35
0.49
c
0.19
0.25
D
4.8
5
E1
3.8
3.9
4
E
5.8
6
6.2
e
1.27 BSC
L
0.4
1.25
h
0.25
0.5
Ɵ
0
7
Ɵ1
2
12
aaa
0.25
bbb
0.25
ccc
0.1
STGAP2S
SO-8 package information
DS12541 - Rev 3
page 16/23
