Ref.

Dimensions in mm

Min.

Typ.

Max.

b1

-

0.15

-

D

9.00 BSC

D1(2)

8.75 BSC

D2

-

6.70

-

e

0.50 BSC

E

9.00 BSC

E1(2)

8.75 BSC

E2

-

6.70

-

L

0.30

-

0.50

L1

0.15 REF

L2

-

0.10

-

P

-

-

0.60

Tolerance of form and position

aaa

0.15

bbb

0.10

ccc

0.10

ddd

0.05

eee

0.08

fff

0.10

1. Maximum allowable burr is 0.076 mm in all directions.

2. D1 and E1 are Maximum plastic body size dimensions including mold mismatch. Dimensions D1 and E1 do not include

mold flash or protrusions. Allowable mold flash or protrusions is "0.25 mm (0.0098 inch)" per side.

Note:

The package is compliant to IPC/JEDEC J-STD-020D June 2007 standard Moisture/Reflow Sensitivity

Classification for Nonhermetic Solid State Surface Mount Devices, MSL Level 3.

TDA7708

VFQFPN-64 (9x9x1.0mm) package information

DB2482 - Rev 5

page 6/8
