5 / 25 page  Data Sheet AD637 Parameter Test Conditions/Comments AD637J/AD637A Unit Min Typ Max dB OUTPUT Error VIN = 7 mV to 7 V rms, 0 dBV ±0.5 dBV Scale Factor −3 mV/dB Scale Factor Tempco +0.33 % of reading/°C −0.033 dB/°C IREF for 0 dB = 1 V rms 5 20 80 µA IREF Range 1 100 µA BUFFER AMPLIFIER Input Output Voltage Range −VS to (+VS − 2.5) V Input Offset Voltage ±0.8 ±2 mV Input Current ±2 ±10 nA Input Resistance 108 Ω Output Current −0.13 +5 mA Short-Circuit Current 20 mA Small Signal Bandwidth 1 MHz Slew Rate 2 kΩ load, to −VS 5 V/µs DENOMINATOR INPUT Input Range 0 to 10 V Input Resistance 20 25 30 kΩ Offset Voltage ±0.2 ±0.5 mV CHIP SELECT (CS) RMS On Level Open or 2.4 < VC < +VS V RMS Off Level VC < 0.2 VC < 0.2 V IOUT of Chip Select CS low 10 µA CS high 0 µA On Time Constant 10 + ((25 kΩ) × CAV) µs Off Time Constant 10 + ((25 kΩ) × CAV) µs POWER SUPPLY Operating Voltage Range ±3.0 ±18 V Quiescent Current 2.2 3 mA Standby Current 350 450 µA Rev. L | Page 5 of 25 |
|
|
