AD637
Data Sheet
dB CALIBRATION
Refer to Figure 20:
•
Set VIN = 1.00 V dc or 1.00 V rms
•
Adjust R1 for 0 dB output = 0.00 V
•
Set VIN = 0.1 V dc or 0.10 V rms
•
Adjust R2 for dB output = −2.00 V
Any other dB reference can be used by setting VIN and R1
accordingly.
25kΩ
25kΩ
COMMON
OUTPUT
OFFSET
DEN
INPUT
dB OUTPUT
–VS
+VS
NIC
+VS
AD508J
+2.5V
R1
500kΩ
10kΩ
4.7kΩ
+VS
–VS
+VS
COMPENSATED
dB OUTPUT
+100mV/dB
BIAS
SECTION
0dB ADJUST
*1kΩ + 3500ppm
SEE TEXT
AD707JN
+VS
R2
5kΩ
33.2kΩ
R3
1kΩ*
BUFFER
AD637
FILTER
1
2
3
4
5
6
7
14
13
12
11
10
9
8
CAV
+
BUFF
OUT
BUFF IN
NIC
CS
VIN
1µF
SIGNAL
INPUT
dB SCALE
FACTOR
ADJUST
–VS
60.4Ω
2
3
4
6
7
ABSOLUTE
VALUE
SQUARER/DIVIDER
NIC = NO INTERNAL CONNECTION
RMS
OUT
Figure 20. dB Connection
Rev. L | Page 18 of 25
