Data Sheet
AD4050/AD4056
PIN CONFIGURATION AND FUNCTION DESCRIPTIONS
analog.com
Rev. A | 12 of 67
Table 10. AD4050/AD4056 LFCSP and WLCSP Pin Function Descriptions (Continued)
LFCSP Pin No.
WLCSP Pin No. Mnemonic
Type
Description
13
C2
CNV
DI
Convert Input. In sample mode, averaging mode, and burst averaging mode, a rising edge on
the CNV pin initiates a conversion. The CNV pin can optionally be connected to CS. See the
Serial Interface section.
14
A2
GP0
DO
General Purpose Output 0. The GP0 pin is a digital output that can be configured as multiple
device control or interrupt signals. See the Interrupts and Control Signals section.
