1 / 5 page  STTH3003CW October 1999 - Ed: 5A HIGH FREQUENCY SECONDARY RECTIFIER ® Dual center tap Fast Recovery Epitaxial Diodes suited for Switch Mode Power Supply and high frequency DC to DC converters. Packaged in TO-247 this device is intended for secondary rectification. DESCRIPTION COMBINES HIGHEST RECOVERY AND REVERSE VOLTAGE PERFORMANCE ULTRA-FAST, SOFT AND NOISE-FREE RECOVERY FEATURES AND BENEFITS Symbol Parameter Value Unit VRRM Repetitive peak reverse voltage 300 V IF(RMS) RMS forward current 30 A IF(AV) Average forward current Tc = 135 °C δ = 0.5 Per diode Per device 15 30 A IFSM Surge non repetitive forward current tp = 10 ms sinusoidal 140 A IRSM Non repetitive peak reverse current tp = 20 µs square 7A Tstg Storage temperature range -65 +175 °C Tj Maximum operating junction temperature +175 °C ABSOLUTE RATINGS (limiting values, per diode) IF(AV) 2 x 15 A VRRM 300 V Tj (max) 175 °C VF (max) 1 V trr (max) 40 ns MAJOR PRODUCT CHARACTERISTICS A1 K A2 TO-247 1/5 |
