ST7SCR

78/102

RECOMMENDED OPERATING CONDITIONS (Cont’d)

(TA=0 to +70

oC, V

DD-VSS=5.5V unless otherwise specified)

Notes:

1. CPU running with memory access, all I/O pins in input mode with a static value at VDD or VSS; clock input (OSC1)

driven by external square wave.

2. All I/O pins in input mode with a static value at VDD or VSS; clock input (OSC1) driven by external square wave.

T = 0... +70oC, voltages are referred to VSS unless otherwise specified:

Note 1 : Hysteresis voltage between Schmitt trigger switching levels. Based on characterisation results, not tested.

Note 2 : Guaranteed by Characterization

Symbol

Parameter

Conditions

Min

Typ.

Max

Unit

IDD

Supply current in RUN mode 1)

fOSC = 4MHz

Supply current in WAIT mode 2)

3mA

Supply current in suspend mode

External ILOAD = 0mA

(USB transceiver enabled)

500

µA

Supply current in HALT mode

External ILOAD = 0mA

(USB transceiver disabled)

100

I/O PORT PINS

Symbol

Parameter

Conditions

Min

Typ

Max

Unit

VIL

Input low level voltage

0.3xVDD

VIH

Input high level voltage

0.7xVDD

VHYS

Schmidt trigger voltage hysteresis 1)

400

VOL

Output low level voltage

for Standard I/O port pins

I=-5mA

1.3

I=-2mA

0.4

VOH

Output high level voltage

I=3mA

VDD-0.8

Input leakage current

VSS<VPIN<VDD

µA

RPU

Pull-up equivalent resistor

170

Ω

tOHL

Output high to low level fall time

for high sink I/O port pins (Port D) 2)

Cl=50pF

tOHL

Output high to low level fall time

for standard I/O port pins (Port A, B or

C) 2)

tOLH

Output L-H rise time (Port D) 2)

tOLH

Output L-H rise time for standard I/O

port pins (Port A, B or C) 2)

tITEXT

External interrupt pulse time

tCPU

LED PINS

Symbol

Parameter

Conditions

Min

Typ

Max

Unit

ILsink

Low current

Vpad > V

DD-2.4

ILsink

High current

Vpad > V

DD-2.4

5.6

8.4
