34 / 102 page ![]() ST7SCR 34/102 I/O PORTS (Cont’d) 9.4 Register Description DATA REGISTERS (PxDR) Port A Data Register (PADR): 0011h Port B Data Register (PBDR): 0015h Port C Data Register (PCDR): 0018h Port D Data Register (PCDR): 0019h Read /Write Reset Value Port A: 0000 0000 (00h) Reset Value Port B: 0000 0000 (00h) Reset Value Port C: 0000 0000 (00h) Reset Value Port D: 0000 0000 (00h) Bits 7:0 = D[7:0] Data Register 8 bits. The DR register has a specific behaviour accord- ing to the selected input/output configuration. Writ- ing the DR register is always taken in account even if the pin is configured as an input. Reading the DR register returns either the DR register latch content (pin configured as output) or the digital val- ue applied to the I/O pin (pin configured as input). DATA DIRECTION REGISTER (PADDR) Port A Data Direction Register (PADDR): 0012h Read/Write Reset Value Port A: 0000 0000 (00h) Bits 7:0 = DD7-DD0 Data Direction Register 8 bits. The DDR register gives the input/output direction configuration of the pins. Each bits is set and cleared by software. 0: Input mode 1: Output mode OPTION REGISTER (PxOR) Port x Option Register PxOR with x = A, B, or D Port A Option Register (PAOR): 0013h Port B Option Register (PBOR): 0016h Port D Option Register (PDOR): 001Ah Read /Write Reset Value: 0000 0000 (00h) Bits 7:0 = OM[7:0] Option register 8 bits. The OR register allows to distinguish in output mode if the push-pull or open drain configuration is selected. Each bit is set and cleared by software. 0: Output open drain 1: Output push-pull PULL UP CONTROL REGISTER (PxPUCR) Port x Pull Up Register PxPUCR with x = A, B, or D Port A Pull up Register (PAPUCR): 0014h Port B Pull up Register (PBPUCR): 0017h Port D Pull up Register (PDPUCR): 001Bh Read /Write Reset Value: 0000 0000 (00h) Bits 7:0 = PU[7:0] Pull up register 8 bits. The PU register is used to control the pull up. Each bit is set and cleared by software. 0: Pull up inactive 1: Pull up active 70 D7 D6 D5 D4 D3 D2 D1 D0 70 DD7 DD6 DD5 DD4 DD3 DD2 DD1 DD0 70 OM7 OM6 OM5 OM4 OM3 OM2 OM1 OM0 70 PU7 PU6 PU5 PU4 PU3 PU2 PU1 PU0 1 |
|
