Section 9 I/O Ports

Rev.1.00 Jun. 07, 2006 Page 492 of 1102

REJ09B0294-0100

Bit

Bit Name

Initial

Value

R/W

Description

TPUMS2

R/W

TPU I/O Pin Multiplex Function Select

Selects TIOCA2 function

0: Specifies P36 as output compare output and input

capture

1: Specifies P37 as input capture input and P36 as

output compare

TPUMS1

R/W

TPU I/O Pin Multiplex Function Select

Selects TIOCA1 function

0: Specifies P34 as output compare output and input

capture

1: Specifies P35 as input capture input and P34 as

output compare

TPUMS0A 0

R/W

TPU I/O Pin Multiplex Function Select

Selects TIOCA0 function

0: Specifies P30 as output compare output and input

capture

1: Specifies P31 as input capture input and P30 as

output compare

TPUMS0B 0

R/W

TPU I/O Pin Multiplex Function Select

Selects TIOCC0 function

0: Specifies P32 as output compare output and input

capture

1: Specifies P33 as input capture input and P32 as

output compare
