AD8557

Rev. C | Page 5 of 24

ABSOLUTE MAXIMUM RATINGS

Table 3.

Parameter

Rating

Supply Voltage

6 V

Input Voltage

VSS − 0.3 V to VDD + 0.3 V

Differential Input Voltage1

±6.0 V

Output Short-Circuit Duration to

VSS or VDD

Indefinite

ESD (Human Body Model)

2000 V

Storage Temperature Range

−65°C to +150°C

Operating Temperature Range

−40°C to +125°C

Junction Temperature Range

−65°C to +150°C

Lead Temperature

300°C

Differential input voltage is limited to ±5.0 V or ± the supply voltage,

whichever is less.

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

THERMAL RESISTANCE

θJA is specified for the worst-case conditions, that is, a device

soldered in a circuit board for LFCSP_VQ packages.

Table 4. Thermal Resistance

Package Type

θJA

θJC

Unit

8-Lead SOIC_N (R)

158

°C/W

16-Lead LFCSP_VQ (CP)

31.5

°C/W

ESD CAUTION
