ABSOLUTE MAXIMUM RATING

PARAMETER

SYMBOL

RATINGS

UNIT

6.0

V

DC Voltage at any Channel Input

6.0

V

Storage Temperature

-65~+150

°C

Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.



STANDARD (RECOMMENDED) OPERATING CONDITIONS

PARAMETER

SYMBOL

MIN

TYP

MAX

UNIT

Operating Supply Voltage

5V_SUPPLY

GND

5

5.5

V

Bias Supply Voltage

LV_SUPPLY

1

3.3

5.5

V

Operating Temperature Range

-40

85

°C



PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP MAX UNIT

Operating Supply Current

5V_SUPPLY=5.0V

110

130

μA

Bias Supply Current

LV_SUPPLY=3.3V

1

5

μA

5V_OUT Overcurrent Output Drop

65

100

mV

5V_OUT Short Circuit Current Limit

5V_SUPPLY=5.0V, 5V_OUT=GND

90

135

175

mA

OFF State Leakage Current, Level

Shifting NFET

LV_SUPPLY 0V

0.1

5

μA

Current Conducted from Output

Pins to V_SUPPLY Rails When

Powered Down

Signal pins: TMDS_D[2:0]+/-,

TMDS_CK+/-,

CE_REMOTE_OUT,

DDC_DAT_OUT, DDC_CLK_OUT,

HOTPLUG_DET_OUT, 5V_OUT

Only

0.1

5

μA

Current Through

CE-REMOTE_OUT When

Powered Down

CEC

CE-REMOTE_IN = LV_SUPPLY<

CE_REMOTE_OUT

0.1

1

μA

VOLTAGE Drop Across Level

Shifting NFET When ON

75

95

140

mV

Top Diode

0.6

0.85

0.95

V

Diode Forward Voltage

Bottom Diode

0.6

0.85

0.95

V

ESD Withstand Voltage, Contact

Discharge Per IEC 61000-4-2

Standard (IEC)

Pins 4, 7, 10, 13, 22, 23, 24, 25,

(Note 2)

±8

kV

Positive

Transients

10.8

V

Channel Clamp Voltage

Negative

Transients

(Note 3)

-2.1

V

Positive

Transients

1.4

Ω

Dynamic Resistance

Negative

Transients

(Note 3)

0.9

Ω
