ELECTRICAL CHARACTERISTICS(Cont.)

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP MAX UNIT

TMDS Channel Leakage Current

ILEAK

0.01

1

μA

TMDS Channel Input

Capacitance

CIN,

TMDS

5V_SUPPLY=5.0V, Measured at

1MHz, VBIAS=2.5V

0.9

1.2

pF

TMDS Channel Input Capacitance

Matching

∆CIN,

TMDS

5V_SUPPLY= 5.0V, Measured at

1MHz, VBIAS=2.5V;

Note 4

0.05

pF

Level Shifting Input Capacitance,

Capacitance to GND

CIN,

DDC

5V_SUPPLY= 5.0V, Measured at

100KHz, VBIAS=2.5V;

Note 2

3.5

4

pF

Level Shifting Input Capacitance,

Capacitance to GND

CIN,

CEC

5V_SUPPLY=5.0V,

Measured at 100KHz,

VBIAS=2.5V

3.5

4

pF

Level Shifting Input Capacitance,

Capacitance to GND

CIN,

HP

5V_SUPPLY=5.0V, Measured at

100KHz, VBIAS=2.5V

3.5

4

pF

Notes: 1. Operating Characteristics are over Standard Operating Conditions unless otherwise specified.

recommended operating conditions, GND=0V and ESD_BYP (pin 39), 5V_OUT (pin 0), and

HOTPLUG_DET_OUT (pin 22) each bypassed with a 0.1µF ceramic capacitor connected to GND.

3. These measurements performed with no external capacitor on ESD_BYP.

4. Intra-pair matching, each TMDS pair (i.e. D+, D-)
