STA310

68/90

When this register is set to 1, the LFE channel is

skipped. When this register is set to 0 the LFE chan-

nel is decoded (if present).

MP_PROG_NUMBER

Program number

Address: 0x69

Type: R/W

Software Reset: 0x00

Hardware Reset: UND

Description:

When the stream is in Second Stereo mode, this reg-

ister specifies which program is played.

MP_DUALMODE

MPEG setup dual mode

Addres: 0x6E

Type: R/W

Software Reset: 0x00

Hardware Reset: UND

The MPEG DUAL_MODE is active in downmix mode

1 and 9.

MP_DRC

Dynamic range control

Address: 0x6A

Type: R/W

Software Reset: 0x00

Hardware Reset: UND

Description;

When bit DRC=1, dynamic range control is enabled.

The dynamic range is set according to the data trans-

mitted in the DVD MPEG stream.

MP_CRC_OFF

CRC check off

Address: 0x6C

Type: R/W

Software Reset: NC

Hardware Reset: UND

Description:

When register is set to 1, the CRC in MPEG frame is

not checked. When register is set to 0, the CRC in

MPEG frame is checked if exists. If a CRC error oc-

curs, the decoder soft mutes the frame (but does not

stop).

MP_MC_OFF

Multi-channel

Address: 0x6D

Type: R/W

Software Reset: NC

Hardware Reset: UND

7654321

Reserved

Prog

Bitfield

Description

Prog

Select program #0 or #1 where 0: L0,R0 in front

channels, 1: L2,R2 in front channels

7654321

Value

Description

Output as Stereo

Output Channel 1 on both outputs L/R

Output Channel 2 on both outputs L/R

Mix Channel 1 and 2 to monophonic, and

output on both L/R

765432

DRC

65432

7654

321

Reserved

DEN

Reserved
