FT234XD USB TO BASIC UART IC
Version 1.2
Document No.: FT_000753 Clearance No.: FTDI#324
Pin No.
Name
Type
Description
1
USBDM
INPUT/OUTPUT USB Data Signal Minus.
12
USBDP
INPUT/OUTPUT USB Data Signal Plus.
2
RESET#
INPUT
Reset input (active low).
Table 3.2 Common Function pins
Pin No.
Name
Type
Description
7
TXD
Output
Transmit Asynchronous Data Output.
10
RXD
Input
Receiving Asynchronous Data Input.
8
RTS#
Output
Request to Send Control Output / Handshake Signal.
11
CTS#
Input
Clear To Send Control Input / Handshake Signal.
6
CBUS0
I/O
Configurable CBUS I/O Pin. Function of this pin is configured in the
device MTP memory. The default configuration is TXDEN. See CBUS
Signal Options, Table 3.4.
Table 3.3 UART Interface and CBUS Group (see note 1)
Notes:
1. When used in Input Mode, the input pins are pulled to VCCIO via internal 75kΩ (approx.) resistors.
These pins can be programmed to gently pull low during USB suspend (PWREN# = “1”) by setting an
option in the MTP memory.
