Part numbering

M24C32-W M24C32-R M24C32-F M24C32-X M24C32-DF

38/42

DocID4578 Rev 24

Part numbering

Table 25. Packaged products ordering information scheme

Example:

M24C32-D

MN 6

P /P

Device type

M24 = I2C serial access EEPROM

Device function

C32 = 32 Kbit (4096 x 8)

Device family

Blank = Without Identification page

D = With additional Identification page

Operating voltage

W = VCC = 2.5 V to 5.5 V

R = VCC = 1.8 V to 5.5 V

F = VCC = 1.7 V to 5.5 V

X = VCC = 1.6 V to 5.5 V

Package

BN = PDIP8 (1)

1. RoHS-compliant (ECOPACK1®)

MN = SO8 (150 mil width) (2)

2. RoHS-compliant and halogen-free (ECOPACK2®)

DW = TSSOP8 (169 mil width)(2)

MC = UFDFPN8 (MLP8) (2)

MH = UFDFPN5 (MLP5)(2)

Device grade

6 = Industrial: device tested with standard test flow over –40 to 85 °C

5 = Consumer: device tested with standard test flow over –20 to 85°C

Option

T = Tape and reel packing

blank = tube packing

Plating technology

P or G = ECOPACK® (RoHS compliant)

Process(3)

3. The process letter is used only when ordering WLCSP packages, the process letter is not specified when

ordering any other package. These process letters appear on the device package (marking) and on the

shipment box. Please contact your nearest ST Sales Office for further information.

/P or /K or /T = Manufacturing technology code
