Application schematic
STLED524
8/72
DocID026217 Rev 1
1
Application schematic
Figure 1. Application schematic
VIN
L
C3
C4 C5
C1
VBAT1 VBAT2
SW
SW
VOUT
VOUT
LDO
ROW0
ROW1
ROW2
ROW3
ROW4
DRIVER
CONTROL
REF1
VSUP
C2
STEP-UP CONVERTER
REFERENCES
ROW[4:0]
VDD
V/O
INT
MOSI
R1
MISO
SCK
COL0
COL1
COL2
COL3
COL4
COL5
COL6
COL7
COL8
COL9
COL10
COL11
COL12
COL13
COL14
COL15
COL16
COL17
COL18
COL19
COL20
COL21
COL22
OSCILLATOR
CURRENT
RF
I/O and
level shifters
SPI interface
+
Digital core
SS
CLKIN
CLKOUT
SYNC
RESET/PWRDN
ISET
RSET
TEST
COL23
GIPG2702141303LM
