T48C862-R4 [Preliminary]

4551C–4BMCU–01/04

Absolute Maximum Ratings: Microcontroller Block

Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. This is a stress rating

only and functional operation of the device at these or any other conditions beyond those indicated in the operational sections of this

specification is not implied. Exposure to absolute maximum rating conditions for extended periods may affect device reliability.

All inputs and outputs are protected against high electrostatic voltages or electric fields. However, precautions to minimize the build-up of

electrostatic charges during handling are recommended. Reliability of operation is enhanced if unused inputs are connected to an

appropriate logic voltage level (e.g., V

DD).

Voltages are given relative to V

Parameters

Symbol

Value

Unit

Supply voltage

-0.3 to + 6.5

Input voltage (on any pin)

SS -0.3 ≤VIN ≤VDD +0.3

Output short circuit duration

short

Indefinite

Operating temperature range

amb

-40 to +125

° C

Storage temperature range

stg

-40 to +150

° C

Soldering temperature (t

≤10 s)

sld

260

° C

Thermal Resistance

Parameter

Symbol

Value

Unit

Thermal resistance

thJA

135

K/W

DC Operating Characteristics

SS = 0 V, Tamb = -40° C to +125° C unless otherwise specified.

Parameters

Test Conditions

Symbol

Min.

Typ.

Max.

Unit

Power Supply

Operating voltage at VDD

VDD

VPOR

4.0

Active current

CPU active

fSYSCL = 1 MHz

DD = 1.8 V

DD = 3.0 V

0.3

0.4

Power down current

(CPU sleep,

RC oscillator active,

4-MHz quartz oscillator active)

fSYSCL = 1 MHz

DD = 1.8 V

DD = 3.0 V

150

µA

Sleep current

(CPU sleep,

32-kHz quartz oscillator active

4-MHz quartz oscillator inactive)

VDD = 1.8 V

DD = 3.0 V

DD = 3.0 V at 85° C

Sleep

0.4

0.6

4.3

1.5

µA

Sleep current

(CPU sleep,

32-kHz quartz oscillator inactive

4-MHz quartz oscillator inactive)

VDD = 3.0 V

DD = 3.0 V at 85° C

Sleep

0.3

3.5

1.0

µA

Pin capacitance

Any pin to V

710
