SSM2804

Rev. 0 | Page 35 of 36

CHIP STATUS REGISTER, ADDRESS 0x0F

This register is read-only.

Table 45. Chip Status Register Bit Map

OCCD

OCHP

Table 46. Chip Status Register Bit Descriptions

Bit Name

Description

Settings

OCCD

Overcurrent for Class-D

0 = normal

1 = overcurrent

OCHP

Overcurrent for headphone

0 = normal

1 = overcurrent

Overtemperature warning

0 = normal

1 = overtemperature warning

Overtemperature error (thermal shutdown)

0 = normal

1 = overtemperature shutdown

SOFTWARE RESET REGISTER, ADDRESS 0x10

This register is write-only.

Table 47. Software Reset Register Bit Map

SOFTRESET

Table 48. Software Reset Register Bit Descriptions

Bit Name

Description

Settings

SOFTRESET

Software reset

00000000 = software reset
