background image
SSM2804
Rev. 0 | Page 24 of 36
CHANNEL C LINE INPUT VOLUME, ADDRESS 0x03
Table 19. Channel C Line Input Volume Register Bit Map
D7
D6
D5
D4
D3
D2
D1
D0
0
0
0
INCVOL[4:0]
Table 20. Channel C Line Input Volume Register Bit Descriptions
Bit Name
Description
Settings
INCVOL[4:0]
Analog Channel C input volume control
See Table 21
Table 21. Descriptions of Channel C Input Volume Register Bits
INCVOL[4:0]
PGA Mode (dB)
Boost Mode (dB)
00000
Mute
Mute
00001
−12
0
00010
−11
0
00011
−10
0
00100
−9
0
00101
−8
0
00110
−7
0
00111
−6
0
01000
−5
0
01001
−4
0
01010
−3
0
01011
−2
0
01100
−1
0
01101
0
0
01110
1
9
01111
2
9
10000
3
9
10001
4
9
10010
5
9
10011
6
9
10100
7
20
10101
8
20
10110
9
20
10111
10
20
11000
11
20
11001
12
20
11010
13
20
11011
14
20
11100
15
20
11101
16
20
11110
17
20
11111
18
20
