- 42 -
JANURARY 18, 2013 | DATA SHEET | Rev 3.5
42
IR3898
6A Highly Integrated SupIRBuck
TM
Single-Input Voltage, Synchronous Buck Regulator
PD-97662
Figure 49b: IRDC3898 Demo board Layout Considerations – Bottom Layer
Analog Ground plane
Power Ground plane
Figure 49c: IRDC3898 Demo board Layout Considerations – Mid Layer 1
Figure 49d: IRDC3898 Demo board Layout Considerations – Mid Layer 2
Single point connection
between AGND & PGND,
should be close to the
SupIRBuck kept away from
noise sources
Feedback
and Vsns trace
routing should be kept away
from noise sources
