HMC1032LP6GE

v01.0712

CloCk Generator with FraCtional-n Pll

& inteGrated VCo, 125 - 350 Mhz

-234

-232

-230

-228

-226

-224

-222

-220

14 MHz Square Wave

25 MHz Square Wave

50 MHz Square Wave

100 MHz Square Wave

REFERENCE Input (mVpp)

100

200

400

Figure 7. reference input

[5] Measured from a 50 Ω source with a 100 Ω external resistor termination. see

ence Input stage section for more details. Full FoM performance up to maximum 3.3 Vpp input voltage.

[6] Measured from a 50 Ω source with a 100 Ω external resistor termination. see

ence Input stage section for more details. Full FoM performance up to maximum 3.3 Vpp input voltage.

Figure 8. reference input

-235

-230

-225

-220

-215

-210

-205

-200

14 MHz sin

25 MHz sin

50 MHz sq

100 MHz sq

REFERENCE Input (mVpp)

100

200

400

800

Figure 9. output rise time

0

50

100

150

100

150

200

250

300

350

Gain Setting 11

Gain Setting 00

FREQUENCY (MHz)

loop Filter

BW (kHz)

C1

(pF)

C2

(nF)

C3

(pF)

C4

(pF)

r2

(kΩ)

r3

(kΩ)

r4

(kΩ)

loop Filter Design

250

3.9

15

n/a

n/a

2.7

0

0

135

91

33

91

91

0.82

1

1

74

150

27

220

220

0.82

1

1

loop Filter Coniguration table

Figure 10. output Fall time

0

50

100

150

200

100

150

200

250

300

350

Gain 11

Gain 00

FREQUENCY (MHz)
