background image
Data Sheet
SSM2519
Rev. 0 | Page 19 of 28
REGISTER SUMMARY
Table 15. Register Summary
Reg
Name
Bits
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
Reset
RW
0x00 PWR_CTRL
[7:0]
S_RST
RESERVED
NO_BCLK
MCS
SPWDN
0x05
RW
0x01 SYS_CTRL
[7:0]
HPF_EN
AMP_LPM
DAC_LPM
APWDN_EN
EDGE
AMCS
ASR
0x30
RW
0x02 SAI_FMT1
[7:0]
RESERVED
SDATA_FMT
SAI
FS
0x02
RW
0x03 SAI_FMT2
[7:0]
BCLK_GEN
LRCLK_MODE
LRCLK_POL
SAI_MSB
SLOT_WIDTH
BCLK_EDGE
RESERVED
0x00
RW
0x04 CH_SEL
[7:0]
RESERVED
CH_SEL
0x00
RW
0x05 VOL_CTRL
[7:0]
VOL
0x40
RW
0x06 GAIN_CTRL
[7:0]
AMUTE
RESERVED
ANA_GAIN
RESERVED
M_MUTE
0x11
RW
0x07 FAULT_CTRL1
[7:0]
RESERVED
OC
OT
MRCV
MAX_AR
ARCV
0x0C
RW
