Serial Interface Status and

Control Register (SISC)

Primary register address: "A"hex

Serial Transmit Buffer (STB) –

Byte Write

Primary register address: "9"hex

The STB is the transmit buffer of the SSI. The SSI transfers the transmit buffer into the shift regis-

ter and starts shifting with the most significant bit.

Serial Receive Buffer (SRB) –

Byte Read

Primary register address: "9"hex

The SRB is the receive buffer of the SSI. The shift register clocks serial data in (most significant

bit first) and loads content into the receive buffer when complete telegram has been received.

Bit 3Bit 2Bit 1Bit 0

Write

MCL

RACK

SIM

IFN

Reset value: 1111b

Read

- - -

TACK

ACT

SRDY

Reset value: xxxxb

MCL

Multi-Chip Link activation

MCL = 1,multi-chip link disabled. This bit has to be set to "0" during

transactions to/from the internal EEPROM

MCL = 0, connects SC and SD additionally to the internal multi-chip link pads

RACK

Receive ACKnowledge status/control bit for MCL mode

RACK = 0, transmit acknowledge in next receive telegram

RACK = 1, transmit no acknowledge in last receive telegram

TACK

Transmit ACKnowledge status/control bit for MCL mode

TACK = 0, acknowledge received in last transmit telegram

TACK = 1, no acknowledge received in last transmit telegram

SIM

Serial Interrupt Mask

SIM = 1, disable interrupts

SIM = 0, enable serial interrupt. An interrupt is generated.

IFN

Interrupt FuNction

IFN = 1, the serial interrupt is generated at the end of telegram

IFN = 0, the serial interrupt is generated when the SRDY goes low (i.e., buffer

becomes empty/full in transmit/receive mode)

SRDY

Serial interface buffer ReaDY status flag

SRDY = 1,

in receive mode: receive buffer empty

in transmit mode: transmit buffer full

SRDY = 0,

in receive mode: receive buffer full

in transmit mode: transmit buffer empty

ACT

Transmission ACTive status flag

ACT = 1, transmission is active, i.e., serial data transfer. Stop or start conditions

are currently in progress.

ACT = 0, transmission is inactive

First write cycle

Bit 3

Bit 2

Bit 1

Bit 0

Reset value: xxxxb

Second write cycle

Bit 7

Bit 6

Bit 5

Bit 4

Reset value: xxxxb

First read cycle

Bit 7

Bit 6

Bit 5

Bit 4

Reset value: xxxxb

Second read cycle

Bit 3

Bit 2

Bit 1

Bit 0

Reset value: xxxxb
