Summary

TFT 5.0” is a TN transmissive type color active matrix TFT liquid crystal display that

use amorphous silicon TFT as switching devices. This module is a composed of a

TFT_LCD module, It is usually designed for industrial application and this module

follows RoHs,

General Specifications

 Size: 5.0 inch

 Dot Matrix: 800 × 3(RGB) × 480 dots

 Module dimension: 120.7 x 75.8 x 23.0 (Max) mm



Active area: 108.0 x 64.8 mm

 Dot pitch: 0.045 x 0.135 mm

 LCD type:

TFT, Normally White, Transmissive

 View Direction: 12 o’clock



Gray Scale Inversion Direction: 6 o’clock

 Aspect Ratio: 16:9

 Backlight Type:

LED, Normally White

 Controller IC: TFP401

or equivalent

 TFT Interface: HDMI

 RTP Interface: USB

 With /Without TP: With RTP(USB)

 Surface: Anti-Glare

*Color tone slight changed by temperature and driving voltage.
