background image
2. LCM PIN Definition(CON4)
Pin
Symbol
Function
Remark
1
NC
No connection
2
5V
Raspberry Pi:Power 5V
3
GPIO02
Raspberry Pi:GPIO02
4
5V
Raspberry Pi:Power 5V
5
GPIO03
Raspberry Pi:GPIO03
6
GND
Raspberry Pi:GND
7
GPIO04
Raspberry Pi:GPIO04
8
GPIO14
Raspberry Pi:GPIO14
9
GND
Raspberry Pi:GND
10
GPIO15
Raspberry Pi:GPIO15
11
GPIO17
Raspberry Pi:GPIO17
12
GPIO18
Raspberry Pi:GPIO18 (Backlight Enable)
13
GPIO27
Raspberry Pi:GPIO27
14
GND
Raspberry Pi:GND
15
GPIO22
Raspberry Pi:GPIO22
16
GPIO23
Raspberry Pi:GPIO23
17
NC
No connection
18
GPIO24
Raspberry Pi:GPIO24
19
GPIO10
Raspberry Pi:GPIO10
20
GND
Raspberry Pi:GND
21
GPIO09
Raspberry Pi:GPIO09
22
GPIO25
Raspberry Pi:GPIO25
23
GPIO11
Raspberry Pi:GPIO11
24
GPIO08
Raspberry Pi:GPIO08
25
GND
Raspberry Pi:GND
26
GPIO07
Raspberry Pi:GPIO07
27
ID_SD
Raspberry Pi:ID_SD
28
ID_SC
Raspberry Pi:ID_SC
29
GPIO05
Raspberry Pi:GPIO05
30
GND
Raspberry Pi:GND
31
GPIO06
Raspberry Pi:GPIO06
32
GPIO12
Raspberry Pi:GPIO12
33
GPIO13
Raspberry Pi:GPIO13
34
GND
Raspberry Pi:GND
35
GPIO19
Raspberry Pi:GPIO19
36
GPIO16
Raspberry Pi:GPIO16
37
GPIO26
Raspberry Pi:GPIO26
38
GPIO20
Raspberry Pi:GPIO20
39
GND
Raspberry Pi:GND
40
GPIO21
Raspberry Pi:GPIO21
Page 4 of 11
