3 / 32 page  Data Sheet ADL5243 Rev. A | Page 3 of 32 SPECIFICATIONS VDD = 5V, VCC = 5V, VCC2 = 5V, TA = 25oC. Table 1. Parameter Conditions Min Typ Max Unit OVERALL FUNCTION Frequency Range 100 4000 MHz AMPLIFIER 1 FREQUENCY = 150 MHz Using the AMP1IN and AMP1OUT pins Gain 18.2 dB vs. Frequency ±50 MHz ±0.97 dB vs. Temperature −40°C ≤ TA ≤ +85°C ±0.07 dB vs. Supply 4.75 V to 5.25 V ±0.03 dB Input Return Loss S11 −10.4 dB Output Return Loss S22 −8.2 dB Output 1 dB Compression Point 18.4 dBm Output Third-Order Intercept ∆f = 1 MHz, POUT = 3 dBm/tone 29.5 dBm Noise Figure 2.8 dB AMPLIFIER 1 FREQUENCY = 450 MHz Using the AMP1IN and AMP1OUT pins Gain 20.6 dB vs. Frequency ±50 MHz ±0.10 dB vs. Temperature −40°C ≤ TA ≤ +85°C ±0.36 dB vs. Supply 4.75 V to 5.25 V ±0.01 dB Input Return Loss S11 −17.8 dB Output Return Loss S22 −16.5 dB Output 1 dB Compression Point 19.5 dBm Output Third-Order Intercept ∆f = 1 MHz, POUT = 3 dBm/tone 38.4 dBm Noise Figure 2.8 dB AMPLIFIER 1 FREQUENCY = 748 MHz Using the AMP1IN and AMP1OUT pins Gain 20.8 dB vs. Frequency ±50 MHz ±0.02 dB vs. Temperature −40°C ≤ TA ≤ +85°C ±0.32 dB vs. Supply 4.75 V to 5.25 V ±0.01 dB Input Return Loss S11 −22.0 dB Output Return Loss S22 −21.6 dB Output 1 dB Compression Point 19.6 dBm Output Third-Order Intercept ∆f = 1 MHz, POUT = 3 dBm/tone 39.6 dBm Noise Figure 2.7 dB AMPLIFIER 1 FREQUENCY = 943 MHz Using the AMP1IN and AMP1OUT pins Gain 19.0 20.3 22.0 dB vs. Frequency ±18 MHz ±0.01 dB vs. Temperature −40°C ≤ TA ≤ +85°C ±0.28 dB vs. Supply 4.75 V to 5.25 V ±0.02 dB Input Return Loss S11 −24.0 dB Output Return Loss S22 −21.5 dB Output 1 dB Compression Point 18.5 19.9 dBm Output Third-Order Intercept ∆f = 1 MHz, POUT = 3 dBm/tone 40.4 dBm Noise Figure 2.7 dB |
|
