Data Sheet
ADL5243
Rev. A | Page 25 of 32
AMP2OUT
20
19
18
17
13
14
15
16
AMP2IN
AMP2IN
C27
C28
L2
9.5nH
NC
ADL5243
2.2pF
λ2
λ1
λ3
NC
NC
1.8pF
C8
10pF
C26
OPEN
R10
0Ω
R12
0Ω
C22
1pF
C23
10pF
Figure 61. AMP2: Matching Circuit at 2140 MHz
AMP2OUT
20
19
18
17
13
14
15
16
AMP2IN
AMP2IN
C27
C28
L2
9.5nH
NC
ADL5243
2.7pF
λ2
λ1
λ3
NC
NC
OPEN
C8
10pF
C26
1.1pF
R10
0Ω
R12
0Ω
C22
1.3pF
C23
20pF
Figure 62. AMP2: Matching Circuit at 2630 MHz
