POUT PER TONE (dBm)

925MHz

943MHz

961MHz

Figure 39. Loop–943 MHz: OIP3 vs. POUT and Frequency, Minimum

Attenuation State

2.11

2.12

2.13

2.14

2.15

2.16

2.17

FREQUENCY (GHz)

P1dB

OIP3

GAIN

Figure 40. Loop–2140 MHz: Gain, P1dB, OIP3 at POUT = 5 dBm/Tone and Noise

Figure vs. Frequency, Minimum Attenuation State

–45

–40

–35

–30

–25

–20

–15

–10

–5

2.00

2.05

2.10

2.15

2.20

2.25

2.30

FREQUENCY (GHz)

S11

S12

S22

Figure 41. Loop

–2140 MHz: Input Return Loss (S11), Output Return Loss

(S22), and Reverse Isolation (S12) vs. Frequency, Minimum Attenuation State

POUT PER TONE (dBm)

2.11GHz

2.14GHz

2.17GHz

Figure 42. Loop–2140 MHz: OIP3 vs. POUT and Frequency, Minimum

Attenuation State

2.57

2.59

2.61

2.63

2.65

2.67

2.69

FREQUENCY (GHz)

P1dB

OIP3

GAIN

Figure 43. Loop–2630 MHz: Gain, P1dB, OIP3 at POUT = 5 dBm/Tone and Noise

Figure vs. Frequency, Minimum Attenuation State

–50

–45

–40

–35

–30

–25

–20

–15

–10

–5

2.50

2.55

2.60

2.65

2.70

2.75

2.80

2.85

2.90

FREQUENCY (GHz)

S12

S22

S11

Figure 44. Loop–2630 MHz: Input Return Loss (S11), Output Return Loss

(S22), and Reverse Isolation (S12) vs. Frequency, Minimum Attenuation State
