5 / 32 page  Data Sheet ADL5243 Rev. A | Page 5 of 32 Parameter Conditions Min Typ Max Unit AMPLIFIER 2 FREQUENCY = 943 MHz Using the AMP2IN and AMP2OUT pins Gain 16.5 dB vs. Frequency ±18 MHz ±0.05 dB vs. Temperature −40°C ≤ TA ≤ +85°C ±0.39 dB vs. Supply 4.75 V to 5.25 V ±0.10 dB Input Return Loss S11 −11.2 dB Output Return Loss S22 −8.1 dB Output 1 dB Compression Point 25.0 dBm Output Third-Order Intercept ∆f = 1 MHz, POUT = 5 dBm/tone 43.3 dBm Noise Figure 5.3 dB AMPLIFIER 2 FREQUENCY = 2140 MHz Using the AMP2IN and AMP2OUT pins Gain 13.0 14.2 15.5 dB vs. Frequency ±30 MHz ±0.03 dB vs. Temperature −40°C ≤ TA ≤ +85°C ±0.50 dB vs. Supply 4.75 V to 5.25 V ±0.09 dB Input Return Loss S11 −10.7 dB Output Return Loss S22 −8.1 dB Output 1 dB Compression Point 26.0 dBm Output Third-Order Intercept ∆f = 1 MHz, POUT = 5 dBm/tone 41.1 dBm Noise Figure 3.7 dB AMPLIFIER 2 FREQUENCY = 2630 MHz Using the AMP2IN and AMP2OUT pins Gain 13.0 dB vs. Frequency ±60 MHz ±0.13 dB vs. Temperature −40°C ≤ TA ≤ +85°C ±0.56 dB vs. Supply 4.75 V to 5.25 V ±0.09 dB Input Return Loss S11 −9.4 dB Output Return Loss S22 −8.3 dB Output 1 dB Compression Point 24.5 dBm Output Third-Order Intercept ∆f = 1 MHz, POUT = 5 dBm/tone 40.4 dBm Noise Figure 4.1 dB DSA FREQUENCY = 150 MHz Using the DSAIN and DSAOUT pins, minimum attenuation Insertion Loss −1.5 dB vs. Frequency ±50 MHz ±0.12 dB vs. Temperature −40°C ≤ TA ≤ +85°C ±0.10 dB Attenuation Range Between maximum and minimum attenuation states 28.8 dB Attenuation Step Error All attenuation states ±0.18 dB Attenuation Absolute Error All attenuation states ±1.35 dB Input Return Loss −13.5 dB Output Return Loss −13.3 dB Input Third-Order Intercept ∆f = 1 MHz, POUT = 5 dBm/tone 45.2 dBm |
|
