6 / 32 page  ADL5243 Data Sheet Rev. A | Page 6 of 32 Parameter Conditions Min Typ Max Unit DSA FREQUENCY = 450 MHz Using the DSAIN and DSAOUT pins, minimum attenuation Insertion Loss −1.4 dB vs. Frequency ±50 MHz ±0.02 dB vs. Temperature −40°C ≤ TA ≤ +85°C ±0.12 dB Attenuation Range Between maximum and minimum attenuation states 30.7 dB Attenuation Step Error All attenuation states ±0.14 dB Attenuation Absolute Error All attenuation states ±0.39 dB Input Return Loss −17.7 dB Output Return Loss −17.4 dB Input Third-Order Intercept ∆f = 1 MHz, POUT = 5 dBm/tone 41.2 dBm DSA FREQUENCY = 748 MHz Using the DSAIN and DSAOUT pins, minimum attenuation Insertion Loss −1.5 dB vs. Frequency ±50 MHz ±0.02 dB vs. Temperature −40°C ≤ TA ≤ +85°C ±0.12 dB Attenuation Range Between maximum and minimum attenuation states 30.9 dB Attenuation Step Error All attenuation states ±0.15 dB Attenuation Absolute Error All attenuation states ±0.30 dB Input Return Loss −17.1 dB Output Return Loss −17.1 dB Input Third-Order Intercept ∆f = 1 MHz, POUT = 5 dBm/tone 40.4 dBm DSA FREQUENCY = 943 MHz Using the DSAIN and DSAOUT pins, minimum attenuation Insertion Loss −1.6 dB vs. Frequency ±18 MHz ±0.01 dB vs. Temperature −40°C ≤ TA ≤ +85°C ±0.13 dB Attenuation Range Between maximum and minimum attenuation states 30.9 dB Attenuation Step Error All attenuation states ±0.15 dB Attenuation Absolute Error All attenuation states ±0.28 dB Input Return Loss −16.0 dB Output Return Loss −15.9 dB Input 1 dB Compression Point 30.5 dBm Input Third-Order Intercept ∆f = 1 MHz, POUT = 5 dBm/tone 48.3 dBm DSA FREQUENCY = 1960 MHz Using the DSAIN and DSAOUT pins, minimum attenuation Insertion Loss −2.5 dB vs. Frequency ±30 MHz ±0.04 dB vs. Temperature −40°C ≤ TA ≤ +85°C ±0.18 dB Attenuation Range Between maximum and minimum attenuation states 30.8 dB Attenuation Step Error All attenuation states ±0.15 dB Attenuation Absolute Error All attenuation states ±0.35 dB Input Return Loss −10.3 dB Output Return Loss −9.6 dB Input 1 dB Compression Point 31.5 dBm Input Third-Order Intercept ∆f = 1 MHz, POUT = 5 dBm/tone 44.7 dBm |
|
